Recently Inspected | Under Power | Pallet Changer | Mitsubishi Control

This Mitsubishi laser cutting system offers proven performance for shops requiring precision cutting capabilities. Recently inspected and operational, it provides reliable service with minimal maintenance requirements.
‍

The ML 3015 LVP features a generous 120" x 60" maximum workpiece capacity and impressive 1180 IPM processing feed rate. Its precision rack and pinion direct drive system enables smooth, simultaneous 3-axis control for complex cutting operations.

‍

Complete with Mitsubishi CNC Control, 35CF Resonator, chiller unit, dust collector, and Schmalz vacuum lift for material handling, this comprehensive system is ready to tackle your most demanding cutting projects while enhancing your shop's productivity and capabilities.

Specifications:
• Motion system: Precision rack and pinion, direct drive
• Travel drive method: X, Y, Z simultaneous 3 axis control
• X-axis stroke: 122.05″
• Y-axis stroke: 61.02″
• Z-axis stroke: 3.53″
• Maximum work piece size: 120.08″ x 60.04″
• Maximum processing feed rate: 1180 IPM
• Maximum workpiece weight: 2050 lbs.
• Table pass height: 33.5″

Rapid travel speeds:
• Single axis: 3345 IPM
• Simultaneous: 4730 IPM
• Minimum command input: 0.001mm/.0001″

Weight and Dimensions:
• Drive motor type: intelligent AC servo
• Machine unit dimensions: 418.5″ L x 90.6″ H x 183″ W
• Total system weight: 26,325 lbs.
• Pallet change time: Approximately 25 seconds
• Pallet changer weight: 4500 lbs.
• Pallet changer drive mechanism: chain
• Installation dimensions: 473.4″ x 227.7″
• Floor space requirement: 750 square feet
• Electrical requirements: 208 VAC +/- 5%, 3 phase, 60 Hz

‍

Also Included:

1. Chiller

2. MicroAir Mist Collector

3. 5’ x 10’ Shuttle Tables
